Description
TECHNICAL SPECIFICATION
GENERAL
Model
Origin20C
Range
Origin
Technology
Valve
Channels
1
ELECTRONICS
Output wattage
High power 20W, mid power approx 3W and low power approx 0.5W
Outputs
Speaker outputs: 3 x 1/4″ jack sockets (16Ω load / 8Ω load), DI out (1/4″ jack)
Inputs
1 x 1/4″ jack instrument input, footswitch
Controls
Gain, boost, tilt, bass, middle, treble, master, presence, powerstem
Effects
None
Effects loop
Yes, Series, Send/Return
SPEAKERS
Speaker configuration
1×10″
Speaker model
Celestion VT-Junior (16Ω, 50W)
Unit impedance
16Ω
VALVES
Preamp valves
3 x ECC83
Power amp valves
2 x EL34
ACCESSORIES
Footswitch
PEDL-90016 included
Cable
Detachable power cable included
DIMENSIONS (INCLUDING FEET AND HANDLE)
Weight
13.9 kg / 31 lbs
Width
520 mm / 20.5″
Height
440 mm / 17.3″
Depth
240 mm / 9.4″
KEY FEATURES
YOU HAVE THE POWER
Our new power reducing technology, Powerstem, allows you to have high, medium or low power modes to suit your environment, from playing small venues to playing in your bedroom.
ADD A LITTLE BOOST
Using the footswitchable gain boost feature you can add that extra level of gain to generate a more overdriven tone.
TILT YOUR SOUND
It may only have one channel but don’t underestimate it. By using the tilt control you can blend the voice between the normal tone and a high treble tone.
UNDERSTANDING YOUR ORIGIN
There are lots of features on the Origin so we’ve made some videos to help you better understand how the Origin can help shape your sound.
