Description
Features
- Flexible, powerful four-voice analog synthesizer
- Fully programmable, with 200 program memories (100 sounds included)
- Voice Mode lets you flexibly configure the four voices
- Automatable 16-step polyphonic note and motion sequencer
- Oscilloscope function shows the waveform visually
- Rugged and stylish with aluminum top panel, chassis-mounted pots, rubber-coated knobs, and real wood back panel
- MIDI, USB MIDI, and Audio Sync for all types of in-studio and live connectivity, including direct sync with SQ1, volca, electribe, and more
Specifications
- Keyboard
- 37-keys (Slim-key, velocity sensitive)
- Sound Generation
- Analog synthesis
- Maximum Polyphony
- 4 voices
- Program
- 200 programs (100 Presets / 100 Users)
Each program includes voice mode and sequence data settings
Up to eight favorite programs can be registered
- Voice Modes
- 8 modes (Poly, Duo, Unison, Mono, Chord, Delay, Arp, Side Chain)
VOICE MODE DEPTH can vary different parameters in each mode
- Main Synthesis Parameter
- VCO1
- Octave, Wave (Saw, Triangle, Square), Pitch, Shape
- VCO2
- Octave, Wave (Saw, Triangle, Square), Pitch, Shape
- VCO2 MODULATION
- Cross Mod Depth, Pitch EG Int, Sync, Ring
- MIXER
- VCO1, VCO2, Noise
- FILTER
- Cutoff, Resonance, EG Int, Filter Type (2-Pole, 4-Pole), Keytrack, Velocity
- AMP EG
- Attack, Decay, Sustain, Release
- EG
- Attack, Decay, Sustain, Release
- LFO
- Wave (Saw, Triangle, Square), EG Mod (Int, Rate, Off), Rate, Int, Target (Pitch, Shape, Cutoff)
- DELAY
- Hi Pass Cutoff, Time, Feedback, Output Routing (Post Filter, Pre Filter, Bypass)
- Sequencer
- 16-step polyphonic sequencer
Motion sequence can be used on up to four parameters
- Controls
- 41 dedicated panel controls deliver immediate parameter access
A slider can control different parameters for each program
- Display
- Real-time OLED oscilloscope provides visual feedback of parameter changes
- Connectors
- Headphones (6.3mm stereo phone jack)
Output (6.3mm monaural phone jack)
Audio In (6.3mm monaural phone jack)
Sync In (3.5mm monaural mini jack)
Sync Out (3.5mm monaural mini jack)
MIDI In
MIDI Out
USB Type B
- Power Supply
- AC adapter (DC9V)
- Power Consumption
- 8 W
- Dimensions (W x D x H)
- 500 x 300 x 85 mm / 19.69″ x 11.81″ x 3.35″
- Weight
- 2.8 kg / 6.17 lbs.
- Included Items
- AC adapter
