- Equipped with the largest, most authentic collection of TR drum machine sounds available
- Analog Circuit Behavior technology provides component-to-component modeling for unrivaled authenticity
- Supports WAV and AIFF samples via SD card slot for layering your own creations with classic TR sounds
- Contains 81 ACB tones and 150 factory samples
- Supports up to 600 seconds total time for all samples at 44.1kHz, a single sample can be up to 180 seconds
- Step sequencer controls 11 instrument parts and 1 exclusive part for the trigger output (1/8″ output)
- Lock parameter values for any sequence step for subtle or extreme variations
- Each pattern offers 3 fill types and 8 pattern variations for big performance potential
- Program a new pattern while the existing one loops for smoother live improvisation
- Built-in audio interface allows you to multitrack directly to your DAW
- 8 analog audio outputs allow you to route your sounds separately for recording or processing
- Control the intensity of the Accent function in real time for dynamic grooves
- Enter steps manually or record your drums in real time to create grooves on the fly
- Original TR-REC behavior provides an authentic TR series programming experience
- 16 backlit per-step pads make pattern creation easy (supports up to 32-step patterns)
- Dedicated Tempo controls and TR-909 Shuffle control lets you create beats that pulse and groove naturally
- Solid MIDI clock sync provides tight timing with external gear, such as the rest of the AIRA series
SPECIFICATIONS
User Drum Kit
128
User Patterns
128
Step Sequencer
11 instrument parts and 1 exclusive part for trigger out
16 steps per 1 variation
8 (A – H) variations per 1 pattern
2 Fill-in patterns per 1 pattern
INST tone
(Tone can be assigned to each 11 instrument parts freely.)
BASS DRUM: 11 ACB tones
SNARE DRUM: 8 ACB tones
TOM: 15 ACB tones
RIM SHOT: 3 ACB tones
HAND CLAP: 5 ACB tones
HI HAT: 8 ACB tones
CYMBAL: 8 ACB tones
PERCUSSION: 23 ACB tones
FM: 72 tones
PRESET SAMPLE: 300 tones or greater
USER SAMPLE (imported form SD CARD for playback): Available format: WAV, AIFF
Total time for all samples: Approximately 600 sec (at 44.1 kHz, mono)
* The maximum length of a single audio file that can be imported is approximately 180 seconds (at 44.1 kHz).
Effects
INST FX: THRU, HPF, LPF, LPF/HPF, H BOOST, L BOOST, L/H BOOST, ISOLATOR, TRANSIENT, COMPRESSOR, DRIVE, COMP+DRV, CRUSHER
REVERB: AMBI, ROOM, HALL1, HALL2, PLATE, MOD, HA-DOU
DELAY: DLY, PAN, TAPE ECHO, PITCH SHIFT
MASTER FX: HPF, LPF, LPF/HPF, H BOOST, L BOOST, L/H BOOST, ISOLATOR, TRANSIENT, TRANSIENT2, COMPRESSOR, DRIVE, OVERDRIVE, DISTORTION, FUZZ, CRUSHER, PHASER, FLANGER, SBF, NOISE, FATTENER, VINYL SIM
Other: SIDE CHAIN (for EXT IN), SCATTER (as one of AUTO FILL IN function)
Display
16 characters, 2 line (backlit LCD)
7 segments, 4 characters (LED)
External Storage
SD Card (SDHC supported) for backup/restore function and import sample data
Connectors
PHONES jack: Stereo 1/4-inch phone type
MIX OUT (L/MONO, R) jacks: 1/4-inch TRS phone type
ASSIGNABLE OUT/TRIGGER OUT (1 – 6) jacks: 1/4-inch phone type
EXT IN (L/MONO, R) jacks: 1/4-inch phone type
TRIGGER OUT jack: Miniature phone type
MIDI (IN, OUT) connectors
USB port: USB type B (Audio, MIDI)
DC IN jack
Power Supply
AC adaptor
Current Draw
2,000 mA
Accessories
AC adaptor
Owner’s manual
Leaflet “USING THE UNIT SAFELY”
SIZE AND WEIGHT
Width
409 mm
16-1/8 inches
Depth
263 mm
10-3/8 inches
Height
58 mm
2-5/16 inches
Weight
2.1 kg
4 lbs. 11 oz.
