The TM-6 Pro Drum Trigger Module from Roland features 500 one-shot sampled sounds, 268 V-Drums sounds, and 80 ready-to-use drum kits for live stage, theater, and recording applications. Drummers can be presented with unknown material with moments to spare or asked to replicate the drum sound from a studio recording; when you add the Roland TM-6 Pro to your favorite acoustic drum kit, the trigger module gives you instant and reliable access to a vast library of drum sounds, on any stage you play.
Original trigger samples can be imported from an SD card. Six trigger inputs are available, and with the optional Y-cable, you can connect up to 12 triggers or pads, while a layer function is available to customize sounds. Built with three sound modify knobs for intuitive control of volume, pitch, decay, or other effects including MFX and Transient, the drum trigger module’s high-speed trigger response faithfully follows your drumming,
LED indicators shows the status of the triggers, even with the lights down, and the TM-6 Pro Drum Trigger Module works as a trigger to MIDI converter with audio interface. An AC adapter is also included.
- Pre-loaded with 500 one-shot sampled sounds, including tones recorded at world-class studios
- 268 V-Drums sounds onboard for expressive drum performance
- 80 ready-to-use drum kits featuring high-quality preloaded sounds
- Original user samples can be imported from SD card to accurately reproduce studio tones onstage
- Six trigger inputs available for connecting up to 12* triggers or pads
(* Requires optional Y-cable)
- Layer function to customize sounds
- Three sound modify knobs for intuitive control of volume, pitch, decay or other effects including MFX and Transient
- Transient effect to control attack and release of drum sounds
- Independent EQ, Transient effect, compressor and MFX for each trigger, plus master comp and master EQ
- High-speed trigger response faithfully follows your drumming
- Backing track audio data can be played directly from SD memory
- Independent volume control for song, click, and headphones
- LED indicators shows status of the triggers, even with the lights down
- Works as a trigger to MIDI converter with audio interface (8 in / 8 out)
| SPECS | Roland TM-6PRO Specs Drum Kits 100 Instruments Preset Instruments: 268 Factory Preloaded Samples: 500 User Sample Import Number of User Samples: Maximum 1000 (includes factory preloaded 500 user samples) Sound Length Total: 48 minutes in mono, 24 minutes in stereo File Formats: WAV (44.1 kHz, 16/24-bits) Effect Types Pad Equalizer: Each pad (head/rim independently) Pad Transient: Each pad (head/rim collectively) Pad Compressor: Each pad (head/rim collectively) Pad Multi-Effects: 30 types, each pad (head/rim collectively) Reverb: 5 types Master compressor Master equalizer Song Player (SD Card) Audio File: WAV (44.1 kHz, 16/24-bit), MP3**Audio files must be saved on an SD card. Display Graphic LCD 128 x 64 dots Connectors Trigger In Jack: 6 x 1/4″ / 6.3 mm TRS phone type Phones Jack: Stereo 1/4″ / 6.3 mm phone type Master Out Jacks (L, R): 1/4″ / 6.3 mm phone type Direct Out Jack: 4 x 1/4″ / 6.3 mm phone type HH CTRL Jack: 1/4″ / 6.3 mm phone type Foot SW Jack: 1/4″ / 6.3 mm TRS phone type MIDI out connector USB Computer Port: USB B type (USB hi-speed audio/MIDI) DC in jack USB Record/Playback Channels Sampling Rate (Original): 44.1 kHz Sampling Rate (with Sampling Rate Converter): 48 kHz, 96 kHz Record: 8 channels Playback: 8 channels Power Supply AC adaptor (9 VDC) Current Draw 453 mA Dimensions (W x D x H) 9.0 x 9.2 x 2.6″ / 22.8 x 23.3 x 6.6 cm Weight 2.2 lb / 1.0 kg Packaging Info Package Weight 5.6 lb Box Dimensions (LxWxH) 13.1 x 12.7 x 5.7″ |
|---|
