Description
SPECIFICATIONS
Sampling Frequency
- 48 kHz
AD Conversion
- 32 bits + AF method
- AF method (Adaptive Focus method) is a proprietary method from Roland & BOSS that vastly improves the signal-to-noise (SN) ratio of the AD and DA converters.
DA Conversion
- 32 bits
Processing
- 32-bit floating point
Patches
- 99 (User) + 50 (Preset)
Nominal Input Level
- MIC IN: -40 dBu (Adjustable)
- INST IN: -10 dBu
Input Impedance
- MIC IN: 4 k ohms
- INST IN: 2 M ohms
Nominal Output Level
- XLR OUT L, R: -40 dBu, -10 dBu (Selectable)
- INST THRU: -10 dBu (Unbuffered)
Output Impedance
- XLR OUT L, R: 600 ohms
Display
- Graphic LCD (132 x 32 dots, backlit LCD)
Controls
- DOWN switch, UP switch, HARMONY switch,
- EFFECT EDIT button, KEY button, MENU button, EXIT button, ENTER button,
- 1 knob, 2 knob, 3 knob,
- GND LIFT switch
Connectors
- MIC IN connector: XLR type, balanced, phantom power (DC 48 V, 10 mA Max)
- INST IN jack: 1/4-inch phone type
- XLR OUT L, R connectors: XLR type
- INST THRU jack: 1/4-inch phone type
- CTL1,2 / EXP jack: 1/4-inch TRS phone type
- MIDI IN connector
- USB COMPUTER port: USB Micro-B type
- DC IN jack
Power Supply
- AC adaptor (PSA series)
Current Draw
- 310 mA (with phantom power)
- 210 mA (without phantom power)
Accessories
- AC adaptor: PSA series
- Owner’s manual
- Leaflet USING THE UNIT SAFELY
