Description
- Maximum Polyphony
- 24 voices
- Tempo
- Quarter note = 40–300
- Time Signature
- 3/4, 4/4, 6/8
- Tones
- Shaker
Maracas
Bell
Whistle
Tambourine
Pandeiro
Claves
Cowbell
Triangle
Guiro
Bongo
Hand clap
Paila
Conga
Cajon
Drums
Metronome
Sound effects - Number of Favorite
- 50
- Rated Power Output
- 7 W
- Speaker
- 10 cm (4 inches)
- Display
- 7 segments, 3 characters (LED)
- DA Conversion
- 24 bits
- Nominal Input Level
- AUX IN: -20 dBu
- Input Impedance
- AUX IN: 22 k ohms
- Nominal Output Level
- LINE OUT: -10 dBu
- Output Impedance
- LINE OUT: 1 k ohm
- Recommended Load Impedance
- LINE OUT: 10 k ohms or greater
- Connectors
- AUX IN jack: Stereo miniature phone type
LINE OUT jack: Stereo miniature phone type
CTL 1, 2 jack: 1/4-inch TRS phone type
DC IN jack - Power Supply
- Alkaline battery (AA, LR6) x 6 (sold separately)
AC adaptor - Current Draw
- 330 mA
- Expected battery life under continuous use
- Alkaline: Approx. 10 hours
*These figures will vary depending on the actual conditions of use. - Accessories
- Owner’s manual
Leaflet “USING THE UNIT SAFELY”
AC adaptor (PSB-1U + AC Cord Set) - Options (sold separately)
- Footswitch: FS-5U
Dual Footswitch: FS-6, FS-7
AC adaptor (PSB-1U)*When purchasing an AC adaptor, be sure to specify the adaptor (from the list that follows) that is designed for the region in which it will be used, and the voltage supplied there.
(PSB-120/PSB-120TW/PSB-230EU/PSB-230UK/PSB-240A) - SIZE AND WEIGHT
- Width
- 210 mm
8-5/16 inches - Depth
- 143 mm
5-11/16 inches - Height
- 127 mm
5 inches - Weight
- 900 g
2 lbs
